− 30 −

ENGLISH GERMAN FRENCH ITALIAN SPANISH

Speaker installation exampleSpeaker installation example

Installation on a floor or shelf

･ Make fine adjustments to the speaker angle. 󰜏Refer to P.32.

･ Adjust the angle of the speaker arm. 󰜏Refer to P.34.

･ Installation summary 󰜏Refer to P.37.

･ Determine the speaker installation angle. 󰜏Refer to P.38 - 39.

･ Install the speaker on the ceiling. 󰜏Refer to P.41 - 47.

･ Make fine adjustments to the speaker angle. 󰜏Refer to P.32.

TD508MK3 only

Ceiling installation

Wall mounting

･ Installation summary 󰜏Refer to P.37.

･ Determine the speaker installation angle. 󰜏Refer to P.40.

･ Install the speaker on the wall. 󰜏Refer to P.41 - 47.

･ Make fine adjustments to the speaker angle. 󰜏Refer to P.32.

The only speaker which can be installed on a wall is the

TD508MK3. The TD510MK2 cannot be installed on a

wall.

Caution

The CB1 mounting bracket available separately should

be used to provide the most flexible installation.

Tip

The CB1 mounting bracket available separately should

be used to provide the most flexible installation.

Tip
